I attached a picture of an early loadtest with
Lance.
Below
pictures of my loadtest to 4.4g. I added 2.300kg in total on the wings and 750kg
on the engine mount.
The
wings deflected by 10 cm. This Loadtest have to be done on every
Lancair in Austria and Germany.
The
airframe and wings made some "noise" , but everything seems to be very
strong...
Dan:
Are
there any documents available of this ~15g loadtest?
I
also added the gross weight increase from Lancair for the
360
Christian
LNC
360/390 95%
< Lancair later raised the "suggested"
max gross weight to 1800 but, if I remember correctly, kept the landing max
weight at 1685. These things were documented in Lancair
< It is interesting that
Lancair's ultimate load limit is 2 times the max G when the usual
STC's planes use 1.5 times. In any event,
< (1685/1800)x4.5G=4.2G,
still a pretty good max G load limit.
