Tim,
Here is a picture of #5. You have to get air to the four corners of the engine. (#2, #6, # 5, #1). Baffle the lower fins of the cylinders to keep cooling air attached to them. The slot in #5 is right in front of the area where the cooling fins have zero height.
Jeff
-----Original Message-----
From: zoelt@sio.midco.net
To: lml@lancaironline.net
Sent: Tue, Sep 1, 2009 7:43 pm
Subject: [LML] Re: Engine cooling
Thanks Barry,
Tim
I don't know if it shows all the mods, but there is a lot of information in the LML mail list archives at:
http://www.lancaironline.net/maillist.html
Zero in on the bottom of the page where Fred Moreno has posted his baffling mods under the heading of
"Drag Reduction"
Check it out.
Barry Knotts, LIV-P Conti TSIO-550
N4XE
zoelt@sio.midco.net wrote:
Could someone direct me to the thread/link to the discussion of IVP engine cooling and baffling? I need to check that I’ve made all the mods to #5 as it and #2 are still too hot.
Thanks,
Tim
N524JG
|
